A durable 2 pole NT50-4 safety switch providing overload protection for 230V systems, suitable for residential, commercial, and industrial electrical installations.
| Principales | |
| Material | PA66 |
| Pole number | 2P |
| Standard | IEC60898 |
| Warranty | 5 years |
The NT50-4 Safety Switch by JIELI is engineered for professional electrical installations requiring consistent protection and strict compliance. Built according to IEC60898 standards, this 2 pole switch supports 230V 50Hz networks and offers current ratings up to 32A.
With a breaking capacity of 1.5kA and a shock withstand voltage of 4kV, the NT50-4 provides reliable performance in distribution boards, machinery control circuits, and commercial electrical systems. Its overload tripping mechanism ensures fast response to abnormal currents, preventing equipment damage and fire risks.
For electricians, contractors, and system integrators, the NT50-4 Safety Switch is a trusted solution for high-quality power distribution projects.
| Complement | |
| Rated current In | 10A,16A,25A,32A |
| Rated voltage Ue | AC 230V |
| Rated frequency | 50Hz |
| Rated overload breaking capacity | 1.5kA |
| Rated shock withstand voltage | 4kV |
| High-voltage insulation | 2kA/1min |
| Tripping style | Overload tripping |
| Protection level | IP20 |
| Fiducial temperature | 30℃ |
| Ambient temperature | -5℃ to +40℃ |
| Storage temperature | -35℃ to +70℃ |
| Mechanic life | 10000 times |
| Electrical life | 4000 times |
| Installation type | Screw fastening card mounting with panel |
| Terminal wiring capacity | 2.5mm² |
| Flame retardant grade | V-0 |
| Tightening torque | 2.0N*m 22In-Ibs |
| Pollution degree | 2 |
| Connection | Cassette connection |
